CP1+3 Automatic Stone Tiles calibration and polishing machine
- PRODUCT DETAIL
TECHNICAL PARAMETERS:
It is a polishing machine with 1 calibrating head and 3 polishing heads.
The machine can be used to polishing marble, granite and concrete
The Max. width is 650mm.
The Max. polishing thickness is from 35 to 200mm.
| CP1+3 | |
| No. of calibrating head | 1 |
| No. of polishing head | 3 |
| Useful working width | 300-650mm |
| Useful working thickness | 35-200mm |
| Power of polishing head | 7.5kw |
ONE COMPLETE SET MACHINE INCLUDING:
Item
Parts Name
Qty.
Function
1
Loading Table
1
Loading slabs
2
Transmit Table
1
Transmitting slabs
3
Auto-Feeding Table
1
Slabs feeding
4
Main Machine
1
Polishing slabs
5
Blower Dry Table
1
Slabs blowing/drying
6
Unloading Table
1
Unloading slabs
7
Air Compressor
1
Supplying compressed air
8
Air Container
1
Container for compressed
9
Air Dryer
1
Air Drying compressed air
10
Assembling Parts
1
For necessary assembly
