FSJ-50T Stone Block Turnover Machine
- PRODUCT DETAIL
Stone Block Turnover Machine
Quarry Block Holder
Stone Block Tilting Machine
Big Granite and Marble Block Turning Machine
The stone block turnover machine is produce according to industrial demands and standard, combine the advantage of similar stone machine. It is widely used for turnover stone blocks.
This automatic machine can run steadily and has less risk soft damage. It’s easy
and safe to operate, also have high processing quality and efficiency, less power
consumption and failure rate.
Which makes our stone turnover machine been widely accepted by the market.
Technical Parameters:
|
Model |
unit |
FSJ-40T |
FSJ-50T |
FSJ-60T |
|
Max.block weight |
kg |
40000 |
50000 |
60000 |
|
Max.block length |
mm |
3000 |
3500 |
3500 |
|
Max.block width |
mm |
2000 |
2300 |
2300 |
|
Max.block height |
mm |
2000 |
2000 |
2000 |
|
Overall dimensions(L*W*H) |
mm |
2500*1900*2100 |
2600*1900*2100 |
2600*1900*2100 |
|
Turning degree |
n0 |
0-90 |
0-90 |
0-90 |
|
Power of main motor |
kw |
3 |
4 |
5 |
|
Gross weight |
kg |
4500 |
5500 |
6000 |
|
