DZQ-1600 Multi-blade Hydraulic stone cutting machine
- PRODUCT DETAIL
- JDZQ-1600 Multi-blade block saw for sawing kinds of stone blocks into slabs of varying thickness with up to 22 pc of diamond saw blades at the mostly..
- The structure of such machine featured of simple and functional,is made up of a sturdy welded stabilized cast iron & steel to ensure maximum stability and utmost precision during sawing.
- The up/down system is setup of Four hydraulic pressurize column,to ensure maximum protection against rust.Patented Lubrication System can vastly reduce maintenance frequency and maintenance costs which means a perfectly block cutter compared with traditional same kind of machine.
-
Model D8 D12 D14 D16 D18 D22 Blade Diameter (Æ1650mm) / (Æ2200) Number of Blades 8(Æ1650x4+Æ980x4) P 12 P 14 P 16 P 18 P 22 P Lifting travel 1000mm/(1300mm) Max. cutting size 3500x1450x
900(1100)mm3500x1500x
90(1100)mm3500x1550x
90(1100)mm3500x1600x
900(1100)mm3500x1600x
900(1100)mm3500x1650x
900(1100)mmPower of main motor 45 KW 55 KW 65 KW 75 KW 90 KW 110/132 KW Water consumption 16 m3/h 20 m3/h 26 m3/h 30 m3/h 34 m3/h 40 m3/h weight »7.5 T »8.0 T »8.5 T »8.7 T »9 T »11.5 T Remark:Customized cutting Width of stone is available for Model No.D14 and D22 (e.d.1650/1850mm) Up & Down Stroke can be lengthened (higher) if there is necessary.
-
